Micros POS Integration

POS System for restaurant

The Ordering Stack system can be installed in a restaurant chain operating on the Oracle Micros POS system. Based on the extensive experience of 3e software house in the integration of the Micros RES 3700 system , we have created an integration module for the Ordering Stack platform. The integration module allows for bi-directional data exchange, which consists of:

1. import of product definitions and their attributes, prices, ingredients, etc.
2. adding a new order from Ordering Stack (to a local POS installation running on Micros
3. updating order status from Micros in the Ordering Stack

These are prerequisities for Micros Integration Module:

1. installed of the Oracle Hospitality RES 3700 Transaction Services Web Interface module
2. installed of the Local Agent Ordering Stack application in a local restaurant chain
3. configured a local Ordering Stack agent

Ordering Stack Local Agent

• This module must be installed on a selected computer in the local restaurant chain. If there are many restaurants, one of the modules must act as MENU_MASTER. This should be marked in the configuration.
• The module with the MENU_MASTER option selected must be configured with access data to the Sybase database containing menu definitions (the access can be in read-only mode).
• If the central configuration database Micros (Enterprise Module) is used, the indication should be just for this database. If the EM is not used, the indication may be the local database in the selected restaurant.
• Another configuration parameter required regardless of whether the module is a MENU_MASTER or not is the address of the RES POS API network service. Through this API Local Agent will add new orders to the local instance of Micros.

AGNIS POS Integration

We have finished new POS integration for Ordering Stack: it is AGNIS, hospitality software suite for hotels and restaurants, popular in Czech Republic.
Our POS integrator takes care of:

• menu synchronization (AGNIS products definitions including prices are sent to Ordering Stack)
• inserting online orders from Ordering Stack into AGNIS POS (from any channel like web, mobile, call center or kiosk)
• uploading local POS orders created on AGNIS into Ordering Stack – it makes possible to use Ordering Stack KDS (Kitchen Display System) regardless of order source

AGNIS Integrator module is based on Ordering Stack open source component pos-integrator-core, which can be used as a foundation for any other Ordering Stack integrator.
